What is Common Array Manager?

Common Array Manager (CAM) is Sun StorageTek’s centralized web-based management software that provides both browser interface and command-line interface (CLI) for configuring and managing arrays on external management hosts. Originally developed by Sun Microsystems and now maintained by Oracle, CAM serves as the primary control interface for enterprise storage arrays.

Key capabilities include:

• Centralized Management: Single interface for multiple storage arrays
• Real-time Monitoring: Performance metrics and health status tracking
• Configuration Management: LUN mapping, RAID configuration, and storage provisioning
• Firmware Updates: Automated firmware management across array families
• Role-based Access: Granular user permissions and authentication

Supported Array Models

CAM supports a comprehensive range of Sun StorageTek storage systems:

Primary Array Families:

• J4000 Series: J4200, J4400, J4500 JBOD arrays
• 2500 Series: 2510, 2530, 2540 FC arrays
• 6000 Series: 6580, 6130 storage arrays
• F5100 Series: Flash storage arrays
• Sun Blade 6000: Blade server storage

The Sun Common Array Manager is specifically designed to manage a specific range of Sun and Oracle products and is not compatible with storage arrays from other vendors.

Common Array Manager vs Modern Storage Management

While newer storage management solutions have emerged, CAM remains relevant for organisations with significant Sun/Oracle storage investments. Here’s how it compares:

Advantages of CAM

Proven Reliability: Decades of enterprise deployment with minimal downtime Deep Integration: Native support for Sun hardware with optimized performance Cost-Effective: No licensing fees for existing Sun storage customers Comprehensive CLI: Scriptable automation capabilities for large deployments

Modern Alternatives

NetApp Manager: Offers advanced features such as automated data tiering, real-time performance analytics, and robust data protection mechanisms that can achieve higher efficiency through intelligent storage management.

Array Monitor Solutions: Focus primarily on oversight and performance of data arrays while common array managers handle data flow, storage, and accessibility management.

Cloud-Native Solutions: Modern hyperscale storage management with API-first architectures

Installation and Setup Guide

Prerequisites and System Requirements

Before installing CAM, ensure your environment meets these requirements:

Operating System Support:

• Solaris: 8, 9, 10, or OpenSolaris
• Linux: Red Hat or SUSE distributions
• Fenêtres: 2003, 2008, XP with Windows Installer 3.1

Exigences matérielles :

• Minimum 2GB RAM (4GB recommended)
• 500MB available disk space
• Network connectivity to storage arrays
• Administrative privileges

Step-by-Step Installation Process

Method 1: GUI Installation

CAM provides three installation-related wizards: GUI software installer for graphical interface installation, CLI software installers for command-line installation, and an uninstaller for removing software.

For Solaris/Linux:

bash

# Download latest CAM from Oracle Support
# Unpack the installation file
chmod +x CAM_6.5.12_solaris.bin
./CAM_6.5.12_solaris.bin

# Follow GUI prompts for:
# - Installation directory selection
# - Network configuration (default port 6789)
# - User account setup
# - Service configuration

For Windows:

powershell

# Run as Administrator
CAM_6.5.12_windows.exe

# Configure during installation:
# - Service account credentials
# - Firewall exceptions for port 6789
# - Integration with Windows services

Method 2: CLI Installation

For automated deployments or remote installations:

bash

# Silent installation with predefined parameters
./CAM_installer.bin -silent -installdir=/opt/CAM -port=6789

# Verify installation
ps -ef | grep CAM
netstat -an | grep 6789

Post-Installation Configuration

Network Configuration

During installation, you will be asked to configure network settings. The default port is commonly 6789, but you can specify an alternative if another application already uses this port.

Firewall Configuration:

bash

# Open required ports
iptables -A INPUT -p tcp --dport 6789 -j ACCEPT
iptables-save

# For Windows
netsh advfirewall firewall add rule name="CAM Port" dir=in action=allow protocol=TCP localport=6789

User Setup and Authentication

Create required system users before first login:

bash

# Create storage management users
useradd -g storage camadmin
useradd -g storage camuser

# Set appropriate permissions
chown -R camadmin:storage /opt/CAM
chmod 750 /opt/CAM/bin/*

Advanced Configuration and Management

Web Interface Access

Access the CAM web interface by opening a supported browser and navigating to https://<server_ip_address>:<port>, where the default port is 6789.

Supported Browsers:

• Firefox 3.0+
• Internet Explorer 8+
• Chrome 10+
• Safari 4+

Command Line Interface (CLI)

The CAM CLI provides scriptable access to all management functions:

bash

# Connect to CAM CLI
sscs connect -h <cam_server> -u <username>

# Common commands
sscs show arrays           # List all managed arrays
sscs show array-status     # Display array health
sscs show luns            # List all LUNs
sscs create lun           # Create new LUN
sscs map lun              # Map LUN to host

LUN Management and Mapping

To assign storage, you must map LUNs to hosts. This process involves associating a specific LUN with the Host Bus Adapter (HBA) World Wide Name (WWN) of the target server, thereby establishing a dedicated data path from the storage array.

LUN Creation Process:

1. Plan Capacity: Determine size and RAID level requirements
2. Create LUN: Use GUI or CLI to provision storage
3. Configure Access: Set up zoning and masking
4. Map to Host: Associate LUN with specific server WWNs
5. Verify Access: Test connectivity and performance

Performance Monitoring and Optimization

CAM provides comprehensive monitoring capabilities:

Key Metrics to Monitor:

• IOPS: Input/output operations per second
• Débit: Data transfer rates in MB/s
• Temps de réponse: Average I/O latency
• Cache Hit Ratio: Storage cache effectiveness
• Taux d'erreur: Failed I/O operations

Performance Tuning Tips:

bash

# Check cache settings
sscs show cache-parameters

# Optimize cache allocation
sscs set cache-read-ahead enabled
sscs set cache-write-policy writeback

# Monitor performance
sscs show performance-statistics

Troubleshooting Common Issues

Performance Problems

Slow Response Times Users report CAM working very slowly with response times exceeding 2 minutes, particularly when running on Windows with Firefox browser.

Solutions:

• Increase JVM Memory: Modify CAM startup scripts to allocate more heap space
• Browser Optimization: Clear cache, disable unnecessary plugins
• Network Tuning: Verify low-latency connectivity between management host and arrays
• Database Maintenance: Regular cleanup of CAM configuration database

Connectivity Issues

Array Discovery Problems:

bash

# Check network connectivity
ping <array_ip_address>
telnet <array_ip_address> 2463

# Verify CAM service status
systemctl status CAM
service CAM restart

# Check logs for errors
tail -f /var/log/CAM/CAM.log

Version Management

Determining the Common Array Manager version is crucial for troubleshooting and patch management:

bash

# Check CAM version via CLI
sscs version

# Check via web interface
# Navigate to Help > About in CAM GUI

# Check installation files
cat /opt/CAM/version.txt

Meilleures pratiques en matière de sécurité

Access Control

Role-Based Permissions:

• Administrator: Full configuration and management access
• Operator: Day-to-day monitoring and basic operations
• Monitor: Read-only access to status and performance data
• Guest: Limited view-only access

Sécurité des réseaux

Secure Communication:

• Enable HTTPS for all web interface access
• Use SSH for CLI connections when possible
• Implement network segmentation for storage management traffic
• Regular security patches and updates

Authentication Integration

bash

# LDAP integration configuration
sscs configure authentication ldap
sscs set ldap-server <ldap_server_ip>
sscs set ldap-base-dn "dc=company,dc=com"

Migration and Upgrade Strategies

Upgrading CAM

When upgrading to a new release, run the install program exactly as described for fresh installation. The install script searches for earlier versions and updates only files that require change, preserving existing settings and data.

Processus de mise à niveau :

1. Backup Configuration: Export current array configurations
2. Test Environment: Validate upgrade in non-production environment
3. Maintenance Window: Schedule downtime for production upgrade
4. Post-Upgrade Validation: Verify all arrays and functions work correctly

Data Migration

Configuration Export/Import: CAM provides the ability to export array configurations or storage profiles for duplicating configurations to another array or restoring reset configurations.

bash

# Export configuration
sscs export configuration -file /backup/array_config.xml

# Import to new array
sscs import configuration -file /backup/array_config.xml -array <target_array>

Integration with Modern Infrastructure

Intégration de l'API

While CAM predates modern REST APIs, integration is possible through:

CLI Automation:

python

import subprocess
import json

def get_array_status():
    result = subprocess.run(['sscs', 'show', 'array-status', '-format', 'json'],
                          capture_output=True, text=True)
    return json.loads(result.stdout)

def create_lun(size, name):
    subprocess.run(['sscs', 'create', 'lun', '-size', size, '-name', name])

Monitoring Integration

SNMP Integration:

• Configure SNMP on storage arrays
• Set up monitoring systems (Nagios, Zabbix, etc.)
• Create custom dashboards for CAM-managed storage

Backup Integration

Data Protection:

bash

# Schedule automated backups
sscs schedule snapshot -lun <lun_id> -frequency daily
sscs configure replication -target <remote_array>

Cost Optimization

License Management

CAM Licensing Benefits:

• No additional licensing costs for Sun storage customers
• Unlimited array management with valid support contract
• Reduced TCO compared to third-party storage management solutions

Resource Optimization

Storage Efficiency:

• Implement tiered storage policies
• Use thin provisioning where appropriate
• Regular capacity planning and cleanup
• Deduplication for compatible workloads

Future Considerations

Legacy System Management

As Sun/Oracle storage arrays age, organizations should consider:

Modernization Path:

• Gradual migration to cloud-native storage
• Integration with hybrid cloud architectures
• Evaluation of next-generation storage management platforms

Continued CAM Usage:

• Maintain skills and documentation
• Regular backup of configurations
• Plan for eventual system replacement

Questions fréquemment posées

What is the difference between Common Array Manager and other storage management tools?

An array monitor primarily focuses on oversight and performance of data arrays while a common array manager is more about managing data flow, storage, and accessibility efficiently. CAM combines both monitoring and management capabilities specifically for Sun/Oracle storage arrays.

Can Common Array Manager work with non-Sun storage arrays?

No, the Sun Common Array Manager is specifically designed to manage a specific range of Sun and Oracle products and is not compatible with storage arrays from other vendors.

What are the system requirements for CAM installation?

CAM supports Solaris, Linux, and Windows platforms with minimum 2GB RAM and 500MB disk space. Network connectivity to storage arrays and administrative privileges are required.

How do I troubleshoot slow CAM performance?

Common solutions include increasing JVM memory allocation, browser optimization, verifying network connectivity, and regular database maintenance. Performance issues often stem from insufficient resources or network latency.

Is Common Array Manager still supported by Oracle?

Oracle continues to provide support for CAM as part of their Sun storage support contracts. However, organizations should plan for eventual migration to modern storage management platforms.

How do I backup and restore CAM configurations?

CAM provides configuration export functionality to save array configurations for duplication or restoration purposes. Use the sscs export configuration command to create backup files.

What’s the latest version of Common Array Manager?

The current version is CAM software 6.5.12, available through Oracle Support with valid support contracts.

Can I automate CAM operations?

Yes, CAM provides extensive CLI capabilities that can be scripted for automation. Python, bash, and PowerShell scripts can interact with the sscs command-line interface for automated storage management.

Conclusion

Common Array Manager remains a critical tool for organizations managing Sun StorageTek storage infrastructure. While newer alternatives exist, CAM’s deep integration with Sun hardware, proven reliability, and cost-effectiveness make it a valuable solution for existing deployments.
